Archive for February, 2009

Our Caiman Under Stars set of photos was shot over the course of three nights last summer. We were in the Pantanal – a massive wetland region of Brazil, over 10 times the size of the Florida Everglades.

Usually we aren’t content with just taking photos during the day so we often go out in search of nocturnal wildlife. On one of our night walks we came across a swampy area where caimans were lying in a channel waiting for fish to swim past. It was a very dark night with no moon but plenty of stars overhead. I’m not sure where the inspiration came from but we decided to try and photograph a caiman with star trails in the sky above.

It would have been easy to get the shot by first photographing the caiman and then compositing a second shot of the stars. However, we wanted to achieve the effect in a single exposure (so that it would be eligible for competitions amongst other things).

Composing the shot by the light of a headtorch was the first challenge. We were using a 16mm lens on a full-frame Canon 1Ds Mk III so the second challenge was getting close enough to the caiman!

We knew from experience that we could get a suitable star trail image using a shutter speed of 40 minutes, aperture of f/4.5 and ISO of 200. Based on these settings, we manually controlled the output of an off-camera speedlite flash to correctly expose the caiman in the foreground. This produced a single flash at the start of the exposure which froze the caiman’s initial position on the sensor. For the remainder of the exposure the caiman could thrash around chasing fish as much as it liked without ghosting the image (of course this only worked because the foreground was completely dark – if there had been a moon or stray torch beams then there would have been ghosting).

One last detail – at f/4.5 it would have been impossible to have both the stars and the foreground in focus. To get over this we first focused on the head of the caiman, started the exposure, triggered the flash and then shifted the focus to infinity as quickly as possible!

Once we set the camera off we had to wait for 40 minutes with our flash-lights dimmed, swatting mosquitos and keeping an eye out for jaguars before we could move on to the next shot. We would take around 4 or 5 shots before midnight then flop into our beds with our alarms set for pre-sunrise so that we could enjoy the good morning light. Needless to say, we left the Pantanal exhausted!

Will and I have been thinking about writing a series of blog posts on some of our favourite images and how they were taken. The aim is to provide a little more explanation behind some of the techniques that we use and to highlight the most important things to consider when you’re taking wildlife photos.

So, I’m kicking off with my mosquito emerging series of photos. As is the case with most of my macro photos, the inspiration behind these shots came from getting outside and actively searching for subjects – you can’t always expect to come up with good ideas whilst sitting on your backside!

I noticed the larvae of these mosquitoes living in a stagnant pot of water in my garden. I did a bit of research into their development and discovered that it takes about 1-2 weeks (depending on the temperature) for them to develop into the adult form that we all know and love! This was perfect, since it gave me a good amount of time to try and come up with a set up to photograph them as they emerged.

Over the course of about 14 days, I maintained a keen eye on their development. I kept the larvae in a glass of distilled water in my room, covering the glass with perforated cling film – I didn’t want my face to suffer any consequences during the night! Once the larvae had turned into pupae, I knew they were close to hatching. As soon as I saw one that had straightened out (normally they are curled up a bit like cooked shrimp), I knew it was about 5 minutes until go-time.

I transferred the mosquito into a custom made pot of water and made final adjustments to the setup. I was using a Canon EOS 5D with an MP-E 65mm macro lens. For the lighting, I had three flash units – a macro ring lite and two supplementary strobes. Additionally, I had two desktop lamps (one 20 Watt and another 40 Watt) to illuminate the green background. Working at such large magnifications meant that I needed plenty of light to keep the ISO low, the aperture small and shutter speed high.

In order to obtain a strong reflection, I had to get an extremely shallow angle with the surface of the water. This effect is known as Total Internal Reflection. An aperture of around f/16 provided a sufficient depth of field, however, using a magnification of around 4x meant that I encountered some softness in my images due to small aperture diffraction.

After the mosquito had fully emerged from the pupal case, it rested on the surface of the water for a few minutes whilst it pumped fluid into its wings to harden them. I took as many photos as I could, but I was limited by how long it took the flashes to recharge to full power. In total the whole process from start to finish took no more than 5 minutes.

It really was an amazing process to observe through my lens and it actually gave me genuine respect for these insects. Of course, if you have any questions about the set up or anything else then leave a comment below.

Wow… I woke up this morning to find London snowier than I have seen it in years. I couldn’t resist the opportunity to pop out during my lunch break and take a few photos.

I wasn’t expecting to be taking photos any time soon so the only camera gear I have up in London with me is my old 1D Mark II and a 45mm tilt-shift lens… an unusual choice of lens but it did the trick!

Here are just a few pictures to give you an idea of what London looks like at the moment.
